| Type | [Fitting] One-Touch / Screw | Fitting Type | Screw Mount Direction |
| Tube Size 1(φ) | 8 | Threaded Adapter Shape | [Elbows] Elbow |
| Body Material | 316 Stainless Steel | Application | Standard |
| Thread Portion Material | 316 Stainless Steel | Seal/O-Ring Material | [Fluororubber] Special FKM (Fluorine Coated) |
| Threaded Adapter Elbow Shape | [Male Elbows] Male Elbow | Compatible Fluid | Water / Air |
| Type Of Connection | BSPT | Connection Screw | 1/4" |
Product Description:
Core Features and Design Advantages
Material and Sealing
SUS316 stainless steel: significantly superior to 304 stainless steel in terms of pitting and chloride corrosion resistance, suitable for high corrosion environments such as chemical and marine industries.
FKM seal: resistant to temperatures up to 150 ℃, compatible with steam and chemical solvents, and does not require lubricating grease, meeting the hygiene requirements of the food/pharmaceutical industry.
Lightweight and Compact Structure
The volume of the KQG series is reduced by 30% compared to the old model, and the weight is reduced by 62%. It is suitable for pipes with a diameter of 3.2~16mm and is suitable for devices with limited space.
Wide Working Condition Adaptability
Pressure range: -100kPa (vacuum) to 1MPa (pressure resistance 3MPa).
Temperature range: -5 ℃~+150 ℃, supporting steam medium.
Applications:
Food and pharmaceutical industry
Aseptic fluid delivery: Oil free design+FKM sealing meets FDA standards, used for filling lines, CIP (in-situ cleaning) steam pipelines (such as model KQG2L16-04S connected to steam disinfection systems).
High temperature disinfection: Resistant to steam at 150 ℃, applied to fermentation tanks and sterilization equipment pipelines.
Chemical and energy equipment
Corrosive medium transmission: SUS316 material is resistant to acids, alkalis, and organic solvents, and is used for chemical agent transportation pipelines (such as sulfuric acid and chlor alkali processes).
Steam power system: The straight through structure (such as KQG2L12-00) optimizes the connection of steam pipelines to reduce the risk of leakage.
Industrial environmental protection equipment
Dust removal system: Connect pulse valve and air bag, used for high-temperature dust environment in cement plant kiln tail and steel plant sintering machine (such as matching DMF-Y submerged valve).
Wastewater treatment aeration: acid resistant medium design, suitable for quick connection of pneumatic pipelines (such as aeration tank control valves).
Automated pneumatic control
Precision equipment integration: Compact structure (such as KQG2L23-M5) is suitable for mechanical arm fixtures, sensor air path connections, and improves space utilization.
Vacuum system: supports -100kPa vacuum environment, used for suction cup control in semiconductor manufacturing.
| Brand: | SMC |
| Dimensions: | 13.7 mm Dia |
| End Style: | Tube x MNPT |
| Fitting/Connector Type: | Elbow |
| Hex Size: | 14 |
| Manufacturer: | SMC Corporation of America |
| Material: | 316 Stainless Steel |
| Name: | SMC KQG2L08-02S 90 deg Elbow, Elbow, 8 mm x R1/4, Tube x MNPT End Style, 316 Stainless Steel |
| Nominal Size: | 8 mm x R1/4 |
| Pressure Rating: | -100 kPa to 1 MPa |
| Product Type: | Simple |
| Series: | KQG2 |
| Temperature Rating: | -5 to 150 |
| Type: | 90 deg |
| Unit Of Measure: | EA |
| UNSPSC: | 40172800 |
| Weight: | 1.00 |
